epygi QuadroM12Li

  • quadro_12li

epygi QuadroM12Li

Small business customers demand feature-rich and price-competitive IP PBX solutions. The QuadroM12Li answers that demand.

Product Description

This solution can offer the smaller offices advanced features previously only available on the QuadroM32x. These features include Automatic Call Distribution (ACD) for call centers, audio conferencing, call recording and barge-in features. Advanced features are purchasable items, so customers can choose what they pay for instead of being locked into a one-size-fits-all solution. Even though the QuadroM12Li is designed for medium-sized offices, the new owner can be comfortable knowing they are using an enterprise-grade solution backed by Epygi’s support and guaranteed reliability. The QuadroM12li is equipped with six (6) ISDN BRI ports for foreign markets, not including North America. The ISDN BRI ports support NT and TE selectable mode options. Small business customers demand feature-rich and price-competitive IP PBX solutions. The QuadroM12Li answers that demand with increased IP ports and enhanced features for medium-sized offices. Included with the system is support for HD audio, point-to-point video and other desktop productivity tools. Also added to the QuadroM12Li are audio input and output ports for music on hold and paging speaker connections. Additional storage options include a compact flash slot or an external FTP server for recorded calls or system backups.


Call Answering Features

Call Queue

Incoming callers can be held in a queue while they listen to a customizable recorded message. The caller can be sent to voicemail or redirected to another extension if no one picks up

Multi-Company Receptionist

One receptionist can answer calls from predetermined PSTN/IP lines, each identified to a specific company

Simultaneous Ring

While covering several managers’ extensions, a receptionist’s phone will ring simultaneously with each extension, showing which manager is being called, with the caller ID

Extension Status

A receptionist’s phone can be used to monitor multiple managers’ phones providing information on the extension’s status (off-hook, on-hook, ringing) before taking action

Call Pickup

Pickup groups may be defined with a group of extensions. Any phone in the office can be used to answer a call that is ringing on another extension within the pickup group

Call Hunt

Allows calls to ring in on a number of lines so that the first available person can answer.

Auto Attendant with Interactive Voice Response

An interactive voice response (IVR) system replaces the human operator and directs callers to the appropriate extensions or voice mailboxes. VoiceXML v2 is an XML-based language (eXtensible Markup Language) created to develop speech user interfaces for telephone users. It engages users through pre-recorded or synthesized audio prompts.

Call Management Features

Call Hold

Keeps one line “off hook” and connected while the user makes or receives a call on another line. The user can take the original part off hold and resume the conversation.

Call Transfer

Transfer enables a user to forward an incoming call to another telephone or extension

Call Waiting

Signals a recipient that he has an incoming call on an engaged line and allows him to hold his current call, in favor of taking the second one and then switching back to his original caller.

Three-way Conferencing

Allows the caller and two other parties to speak together on one connection.

Call Park

When a call is placed in “park” it is put on hold at a specific extension number to be resumed by someone at another phone. That person can pick up the call by keying the displayed extension number. If no one is available to take the call at the other location, it will “ring back” to the original extension alerting the person who originally parked the call.

Call Screening Features

Direct Transfer to a Voicemail Box

Allows a caller to be transferred directly to the voicemail of another user.

Call Blocking

Prevents calls from reselected numbers from ringing through, giving users the opportunity to avoid unwanted callers

Hiding Caller ID

A caller can block her phone number from being identified by the call recipient

Do Not Disturb

User instructs PBX to route all his incoming calls directly to voice mail. The phone on his desk does not ring.

Away from the Phone

Receive Notification of System Events via Text Message

Choose to receive notice of “events” (calls, voice mails, etc.) from the PBX to your mobile phone as a text message.

Voice Mail

Also known as a VMS, voice mail is a centralized system of managing phone messages for a group of people. Voice mail allows users to receive, answer and manage their phone messages from different locations, sometimes tailoring a response to different callers.

Call Forwarding

Allows users to program the PBX to automatically redirect incoming calls to another number–a mobile phone or home phone for example.

Unified Messaging

Integrates different message types: voice mail, email, text messaging, fax, into a single box that is accessible from a variety of devices: phone, PC, mobile phone, PDA.



Room to room communication on telephone sets


Callers who get a busy signal will be alerted if the line they are calling becomes available during a specified period of time. A distinctive ring functions as an alert for when the call is connected. One need only pick up the phone to be connected to the number they were trying to reach.

Speed Dial

The user “saves” frequently called numbers so that they can be dialed with an assigned shortcut of two or three digits.

Corporate Directory

Provides users with the ability to scroll through a company directory list of names and numbers and dial automatically

Call Paging

User dials in to overhead or external speakers to make voice announcements. Can be set up with speakerphones or specific groups of speakerphones


Hold Music (WAV File Upload)

Allows callers to hear music or a recorded message while on hold or waiting for other participants to arrive for a conference call

T.38 FAX, FAX Relay and Clear Channel Fax

The T.38 fax relay standard permits faxes to be transported across IP networks between existing fax terminals. A clear channel gives full use of the bandwidth for this purpose.

Cost and Bandwidth Saving Features

Call Statistics

The ability to track and report facts (call recipient, length of call, on-hold time, etc.) on incoming and outgoing calls per extension

Dial Plans (call routing)

Calls can travel through a network along a pre-determined path to accomplish a specific goal. Call routing helps determine the least expensive way to make a call or the least congested path to take. Incoming calls can be grouped according to area code and routed to specific customer service reps who manage different geographic regions.

Time of Day Dialing

Creates the ability to route callas according to times of day, enabling users to reselect where a call will come to them during different time periods.

Special IP Phone Support

Distinctive Ringing on IP Phones

Program Aastra or Snom phones to produce distinctive ring sounds for identified callers and categorize incoming calls made to direct lines (service, sales, billing, etc.).

Directory for Aastra and Snom Phones

Quadro IP PBX can automatically load a directory of company extensions onto SNOM 360 and Aastra 480i phones (using simple XML scripting). Users mouse-click on their computers to dial company extensions through their telephones.

Lifeline Port

In the event of power failure, Quadro provides access for one dedicated phone to the PSTN network for emergency services (except ISDN models)

Administrative Functions

Enhanced IP Phone Support

Certain popular IP phones can be automatically configured by the Quadro resulting in a plug and play installation

Quadro FXO Auto Configuration

Quadro IP PBX detects and automatically configures ports added via the Quadro. The new ports appear in the IP PBX GUI.

Voicemail Setup via Phone

Voice-enabled wizard guides users through setting up the personal recorded username, password and voicemail greeting for each extension

CDR Tags for Billing

Eliminates hand-coding of invoices by department, etc.

Daylight Savings Time Adjustment

Quadro IP PBX automatically adjusts for daylight savings time.

Automatic Backup/Download of Quadro Configuration

Automatic scheduled backups and downloads of Quadro’s configuration to a LAN PC or WAN location

Automatic Quadro Firmware Update

Quadro detects newer versions of its IP phone firmware and automatically installs updates from an Epygi-hosted site

IP Phone Plug-and-Play

IP phones automatically acquire an extension on the system and auto-configure without user intervention

Automatic Firmware Updates for Aastra and Snom IP Phones

Quadro identifies the firmware on each installed IP phone (Aastra and/or Snom) and automatically loads proper firmware version
