Alloy 24 Port POE VoIP Switch with 2 uplink ports

POEFEM24T2SFP 26-Port Managed PoE Fast Ethernet Switch

The POEFEM24T2SFP features 24 PoE compliant ports running at 10/100Mbps and 2 uplink ports in a paired mini-GBIC (SFP) and Copper /10/100/1000Mbps configuration. This switch is designed for high port density PoE applications such as VoIP phone deployment or IP security camera environments.

The Intelligent Layer 2 SNMP management features enable reliable transport of critical VoIP and Security data, even in congested network environments. VoIP requires prioritisation of Voice Calls over general Network Data and Security system requires not only prioritisation, but also port based link security and reporting of link failures to intelligent SNMP applications. These and other intelligent network features are all supported from the POEFEM24T2SFP switch.

The POEFEM24T2SFP supports the IEEE 802.3af PoE standard for Power Injection (PSE). This injects PoE power onto the Cat5 Cable when it detects the presence of a PoE complaint device. When operating with non PoE devices the switch will shut down the power injecting circuitry and as such not cause any damage to your network devices but still allow them to run on the switch as in the case of a normal Ethernet device. The POEFEM24T2SFP uses a injection voltage of about 48VDC on pins 1, 2, 3, 6.

Other Intelligent Network features offer a complete management solution that can enable you to scale your network from a single departmental switch right up to any Enterprise environment. STP and RSTP offers network redundancy features, IGMP snooping offers support for Streaming Video and Multicasing images, Tagged Vlan offers logical security and management of nodes within defined groups. QOS based on port priority queues and TOS bytes ensure effient forwarding of critical network data.

ONETEC also offers a complete range of Fibre SFP / Mini GBIC modules for distances from 220 meters to 100Kms.

Product Features:

24x Ports 10/100Mbps TP and 2x Ports Paired Gigabit TP/SFP
Supports 24x ports 10/100M TP ports with Nway and auto MDIX function indication
Supports hot swapping of SFP transceiver modules
Non-blocking, store-and-forward and shared-memory switching technology
Supports auto-negotiation for configuring speed and duplex settings
Supports 802.3x flow control for full-duplex ports
Supports collision-based and carrier-based backpressure for half-duplex ports
256-entry Multicast Address table
Any port can be disabled, forced to a particular speed or set to NWay mode
Per-port ingress/egress rate control with 64K/128K/256K (up to 100Mbps) resolution
Supports Head of Line (HOL) blocking prevention
Supports broadcast storm filtering
8K MAC addresses with automatic learning and aging
Auto-aging with programmable inter-age time
Supports 802.1p Class of Service with 4-level priority queuing
Supports port mirroring function with 3 modes:
(TX Monitor Mode, RX Monitor Mode and TX-RX pair Monitor Mode)
Supports port-based VLAN, 802.1Q tag-based VLAN with up to 256 entries
Efficient self-learning and address recognition mechanism enables forwarding rate at wire speed
Web-based management provides the ability to completely manage the switch from any web browser
SNMP/Telnet interface delivers complete in-band management
Supports IEEE 802.1d Spanning Tree Protocol
Supports ingress port security mode for VLAN Tagged and Untagged frame process
Supports SNMP MIB2 and RMON sampling with sampled packet error indication
24 ports of IEEE 802.3af compliant PoE PSE Ports
Endpoint with 48VDC power through RJ-45 pins 1, 2, 3, 6
Powered Device(PD) auto detection and classification
Supports IEEE 802.1w Rapid Spanning Trees
Supports IEEE 802.1x port-based network access control
Supports IP Multicasting to implement IGMP Snooping function
Supports 802.3ad port trunking with flexible load distribution and failover function
PoE-PSE status and activity LED indicator
Smart feature for PD on/off, class, feeding priority
